Key Standards for Instrumentation and Electrical Systems, Organised by Task
On this page
I&E engineers work with many standards, often without noticing: the tag letters on a P&ID, the colour of a thermocouple cable, the IP rating of an enclosure and the zone marking on a transmitter all come from standards. This page lists the most useful ones by task. Legal requirements differ between countries; always check which editions and local regulations apply to your project.
Documentation and symbols
| Standard | Scope |
|---|---|
| ANSI/ISA-5.1 | Instrument symbols and identification (tag letters, bubbles, lines) |
| ISA-5.4 | Instrument loop diagrams |
| ISO 14617 / ISO 10628 / IEC 62424 | Graphical symbols and P&ID conventions used internationally |
| IEC 81346 | Reference designation of plant objects |
See P&ID Standards.
Sensors and measurement devices
| Standard | Scope |
|---|---|
| IEC 60584 | Thermocouples: voltage tables, tolerance classes, colour codes |
| IEC 60751 | Industrial platinum resistance thermometers (Pt100) |
| ISO 5167 | Flow measurement with orifice plates, nozzles, Venturi tubes and cone meters |
| EN 837 | Pressure gauges (Bourdon tube, diaphragm, capsule) |
| IEC 60770 | Evaluation of transmitter performance |
| IEC 61298 | General methods for evaluating process measurement devices |
| IEC 60534 | Industrial process control valves (sizing, testing, leakage classes) |
Signals and diagnostics
| Standard | Scope |
|---|---|
| NAMUR NE 43 | Failure signal levels for 4–20 mA transmitters |
| NAMUR NE 107 | Standard status categories for field device diagnostics |
| IEC 61158 / IEC 61784 | Fieldbus and industrial Ethernet protocols |
| HART specifications (FieldComm Group) | HART communication |
See Signal Conditioning and Data Acquisition and HART Protocol.
Hazardous areas and enclosures
| Standard or scheme | Scope |
|---|---|
| IEC 60079 series | Explosive atmospheres: area classification, protection concepts (Ex i, Ex d, Ex e…), installation, inspection |
| ATEX directives (EU) | Legal requirements for equipment and workplaces in explosive atmospheres |
| IECEx | International certification scheme based on IEC 60079 |
| NEC Articles 500–506 (US) | Class/Division and Zone systems in North America |
| IEC 60529 | Degrees of protection by enclosures (IP codes) |
Electrical installation and equipment
| Standard | Scope |
|---|---|
| IEC 60364 | Low-voltage electrical installations, including earthing systems |
| IEC 61439 | Low-voltage switchgear and control panel assemblies |
| IEC 60947 series | Contactors, circuit breakers, motor starters |
| IEC 60204-1 | Electrical equipment of machines |
| IEC 60034 | Rotating electrical machines, including efficiency classes (IEC 60034-30-1) |
| IEC 61800 | Adjustable-speed electrical drives |
| IEC 62305 | Lightning protection |
| IEC 61643 | Surge protective devices |
| NFPA 70 (NEC) | US electrical installation code |
EMC and power quality
| Standard | Scope |
|---|---|
| IEC 61000-6-2 / 6-4 | Generic immunity and emission requirements for industrial environments |
| IEC 61326-1 | EMC for measurement, control and laboratory equipment |
| IEC 61000-4-30 | Power quality measurement methods |
| IEEE 519 | Harmonic control in power systems |
See EMI/EMC Testing and Power Quality Analysers.
Safety
| Standard | Scope |
|---|---|
| IEC 61508 | Functional safety of electrical, electronic and programmable systems |
| IEC 61511 | Safety instrumented systems in the process industry |
| ISO 13849 / IEC 62061 | Safety of machinery control systems |
| NFPA 70E | Electrical safety in the workplace (US) |
| IEEE 1584 | Arc flash hazard calculations |
| IEC 61010-1 | Safety of electrical test and measurement equipment (including measurement categories CAT II–IV) |
See Functional Safety and Electrical Hazard Prevention.
Calibration and metrology
| Standard or document | Scope |
|---|---|
| ISO/IEC 17025 | Competence of testing and calibration laboratories |
| JCGM 100 (GUM) | Guide to the expression of uncertainty in measurement |
| JCGM 200 (VIM) | International vocabulary of metrology |
| ISO 10012 | Measurement management systems |
See Calibration and Standardisation.
Standards by project phase
| Phase | Typical standards |
|---|---|
| Design | ISA-5.1, IEC 60079 (classification), IEC 60364, IEC 61511 or ISO 13849 |
| Specification and purchase | IEC 60584, IEC 60751, ISO 5167, IEC 60534, IEC 60529, NE 43/NE 107 |
| Installation | IEC 60079-14, IEC 60364, IEC 61439, IEC 62305 |
| Commissioning and inspection | IEC 60079-17, loop checks, functional safety validation |
| Maintenance | ISO/IEC 17025 calibration, NFPA 70E or local electrical safety rules |
Frequently asked questions
Which standard defines instrument tag letters?
ANSI/ISA-5.1 defines the identification letters and symbols used on P&IDs, such as FT for flow transmitter or LIC for level indicating controller.
What is the difference between ATEX and IECEx?
ATEX is a set of European Union directives with legal force in the EU. IECEx is an international certification scheme based on the IEC 60079 standards. Many products carry both.
Which standard covers thermocouples?
IEC 60584 covers thermocouple reference tables, tolerance classes and colour codes internationally; ASTM E230 is commonly used in North America.
Key takeaways
- Standards govern documentation, devices, signals, hazardous areas, installations, safety and calibration.
- Know which standards and editions your project and country require.
- Name standards in specifications so compliance can be checked.
- Keep calibration traceable through ISO/IEC 17025 laboratories.
